Product Number: VWS-12-AB-FP-EN
Flush-mounted wall speaker with a black ABS-plastic housing for Voice alarm Applications, certified EN 54- 24, suitable for voice announcements and background music with excellent sound quality in buildings.
The VWS-12-AB-FP-EN is designed with two independent speakers and 100V transformers to enable an economic operation of two separated speaker lines (A/B-lines) for highest security demands. In case of a failure of one speaker line the redundancy of the chassis and the transformers will guarantee unimpaired function.
Read More Order Inquiry
Description
Flush-mounted wall speaker with a black ABS-plastic housing for Voice alarm Applications, certified EN 54- 24, suitable for voice announcements and background music with excellent sound quality in buildings.
The VWS-12-AB-FP-EN is designed with two independent speakers and 100V transformers to enable an economic operation of two separated speaker lines (A/B-lines) for highest security demands. In case of a failure of one speaker line the redundancy of the chassis and the transformers will guarantee unimpaired function.
The 2 x 6W powered speaker is equipped with two full range loudspeakers and two 100V transformer with 3 power adjustments, each. For additional reliability, a 2×2-pin-ceramic block, thermal fuses are provided and the speaker chassis are impregnated against wetness.
The speaker is also secured with protection class IP 21C against the security risks of environmental infl ences.
The connecting cables can be supplied by 2 rubber grommets on each side of the rear housing. The speaker is also compliant with the British Standard BS 5839, Part 8. Quick and easy mounting with screws.
• Quick mounting
• Highest reliability
• BS 5839
Technical Specs
Technical Data (Electrical)
| Feature | Description |
| Power | 2×6/3/1,5 W |
| Impedance (100V) | 2 x 1667/3333/6667 ohm |
| Frequency Range | 126 – 12.300 Hz (single) 139 – 12.200 Hz (double) |
| Frequency Response | 93 – 15.400 Hz (single) 106 – 15.400 Hz(double) |
| SPL 1W/1m, peak | 95,7 dB (single) 101,6 dB (double) |
| SPL , 1W/4m, peak | 83,7 dB (single) 89,6 dB (double) |
| SPL Pmax/4m, peak | 91,4 dB (single) 97,3 dB (double) |
| SPL, rated noise power / 4m | 84,0 dB (single) 90,0 dB (double) |
| Sensitivity EN54-24, 1W/4m | 77,0 dB (single) 80,0 dB (double) |
| Sensitivity EN54-24, 1W/1m | 89,0 dB (single) 92,0 dB (double) |
| Dispersion -6dB, 500Hz | single h/v 180°/ 175° double h/v 180°/175° |
| Dispersion -6dB, 1KHz | single h/v 160° double h/v 160°/150° |
| Dispersion -6dB, 2KHz | single h/v 160°/150° double h/v 100°/75° |
| Dispersion -6dB, 4KHz | single h/v 120°/60° double h/v 40°/35° |
Technical Data (Mechanical)
| Feature | Description |
| Dimensions | 255 x 194,5 x 87 mm |
| IP Rating | IP21 |
| Temperature range | -10 / +55 C° |
| Mounting | Screws |
| Connector | 2-pin ceramic block |
| Colour | white |
Order code
| Part No. | Description |
| VWS-12-AB-FP-EN | 12W Wall Mount Speaker, Class-AB, ABS, Flush Mount, Thermal Fuse, Certiifed EN54-24 |
Downloads
| (452.83 KB) |
|
